Farmall 25SC Subcompact Tractor
The Case IH Farmall 25SC delivers 24.7 horsepower with 17.2 PTO horsepower, giving property owners and lifestyle farmers the right balance of strength and versatility in a compact frame. Despite its size, this subcompact doesn’t compromise on durability — it’s engineered to handle mowing, landscaping, loader work, and everyday property maintenance with ease.

Operator comfort comes standard, with an open-air platform featuring a flat floor for easy access and ergonomically placed controls that keep operation simple and intuitive.

With modern styling, durable construction, and a full range of compatible attachments, the Farmall 25SC is more than just a subcompact — it’s a reliable partner for work and lifestyle.

The Working Environment

The open-air platform balances style and function. Easily accessible controls are not in the way when entering or exiting. And the flat platform means no jumping over a transmission hump.

Front Axle

Get the Traction You Need. The Farmall subcompact comes standard with four-wheel drive, letting you tackle even the toughest jobs with ease.

Foldable ROPS

The standard fold-down roll bar allows you to move into low clearance areas quickly and easily.

Mid PTO

The standard mid PTO (2,500 rpm) allows you to use implements such as a mid-mount mower.

Lift Capacity

The Farmall 25SC is equipped with a Category 1 three-point hitch featuring chain-type stabilisers and fixed link ends. With a lift capacity of 450 kg at the ball ends and 330 kg at 610 mm, it’s perfectly suited for a variety of light to medium-duty implements.

ENGINE
  • Emissions Level – Tier 4 B/Final
  • Gross Horsepower – 24.7 hp (18.4 kW)
  • Rated Speed – 3000 rpm
  • Number of Cylinders – 3
  • Aspiration – Natural
  • Displacement – 1.26L
  • Alternator – 50 amps
  • Fuel Tank – 25 L
  • PTO Horsepower – 17.2 hp (12.8 kW)
  • PTO Speed – 540 rpm
  • PTO Type – Independent Electro-Hydraulic
  • Mid-PTO – Standard
  • Mid-PTO Speed – 2500 rpm
  • Type – 2 Range Hydrostatic / Dual Pedal
  • Maximum Forward Speed – 13.3 kph
  • Cruise Control – Standard HST
  • Gear/Shuttle Type – Synchro
  • Rear Diff-lock Engagement – Mechanical
  • Brake Type -Wet Multi-Disc
  • Implement Hydraulic Flow – 17.1 L/min
  • Steering Hydraulic Flow – 8 L/min
  • Total Flow – 25.4 L/min
  • Remote Valves – 1 Optional
  • 3-Point Hitch – Chain Type Stabilizers /Fixed Link Ends
  • 3-Point Lift Capacity @ ball ends – 450 kg
  • 3-Point Lift Capacity @ 24 in. (610 mm) behind ball ends – 330 kg
  • 3-Point Linkage – Category I
  • Selectable 4WD

WITHOUT ATTACHMENTS

  • Wheelbase – 1425 mm
  • Length – 2579 mm
  • Width – 1187 mm
  • Height top of ROPS – 2358 mm
  • Shipping Weight – 650 kg
