Farmall JXM ROPS 55hp - 65HP - 75hp
Farmall JXM Series (JXM55 | JXM65 | JXM75 | JXM90)
More Power. More Options. More Comfort.
The Case IH Farmall JXM Series delivers dependable performance and versatility across four models, from 55 to 90 horsepower. Built for productivity in every field and every season, these tractors combine fuel-efficient powerhouse engines, a heavy-duty compact frame, and premium operator comfort in one capable package.
Choose from 12×12 or 20×20 synchro transmissions, with optional creeper or Power Shuttle configurations, to match your exact needs and working style. Whether handling loader work, tillage, or transport, the Farmall JXM Series is designed to do it all — any task, any time, anywhere.
Farmall JXM Series – Built for power, comfort, and choice.
Operator comfort comes standard, with an open-air platform featuring a flat floor for easy access and ergonomically placed controls that keep operation simple and intuitive.
With modern styling, durable construction, and a full range of compatible attachments, the Farmall 25SC is more than just a subcompact — it’s a reliable partner for work and lifestyle.
Premium Comfort
A flat-deck platform provides easy access and optimised control placement for greater comfort. Suspended brake and clutch pedals are ergonomically positioned, ensuring effortless operation throughout the workday.
Heavy-Duty Rear Axle
The robust straight rear axle efficiently transmits high power and torque with minimal loss. Its durable design ensures quiet operation, extended brake life, and dependable performance in demanding conditions.
Handle Your Operations Like a Pro
ENGINE JXM55-65-75
- 3 cylinder Turbo charged
- JXM65 and JXM75 includes Intercooler
- JXM55 – 55hp(41kw), 49 PTO hp, 220 Nm Torque
- JXM65 – 65hp(48kw), 57 PTO hp, 270 Nm Torque
- JXM75 – 75hp(56kw), 67 PTO hp, 306 Nm Torque
- 30% Torque Rise
- Fuel Tank 40L optional 60L
ENGINE JXM90
- 4 cylinder Turbo charged Aftercooler
- 88hp(65.7kw), 76 PTO hp, 340 Nm Torque
- 25% Torque Rise
- Fuel Tank 90L
PTO
- Independent PTO – Dry Clutch
- 2-speed 540 / 540E
TRANSMISSION
- Synchro and Power Shuttle Options available
- 12 x 12 Mechanical Transmission. Creep options available in some models for 20 x 20 transmission
HYDRAULIC AND LINKAGE
- Top Link sensing draft
- CAT II linkage connection
- Main Pump Hydraulic Flow 60 l/min
- Steering Pump Flow 31 l/min
- Mid-Mount Valve optional
- Up to 3 sets or rear remotes available
WEIGHTS AND DIMENSIONS
- Overall Length JXM55, 65, 75 – 3875mm
- Overall Length JXM90 – 4059mm
- Refer to brochure for all additional dimensions
