Description

ENGINE

? FARMotion LCR Diesel Engine

? 3 Cyl/2887cc Turbocharged Intercooled

? Liquid/Oil Cooled

? Engine speed programming

? High Pressure Diesel Injection/Common Rail

? 76Hp @ 2200 rpm (ECE R120)

? Torque 341 Nm @1500 rpm

? Side mounted upswept exhaust — Tractor

only

? Down swept exhaust – Tractor + FEL

? 75It Fuel Capacity

TRANSMISSION

? 15/15 Forward/Reverse Gears

? Wet Clutch Power Shuttle

? Shuttle Modulation with 5 Settings

? 5 Speeds/3 Ranges/298 m/hr –40 Km/h ECO

? Comfort Clutch with Stop and Go Function

? Wheel Independent Braking

? Push Button 4WD and Diff lock 100% Locking

? Pre-Arrangement For Front End Loader

PTO

? Independent Rear PTO

? 540/ 750 Speed PTO

? 540 PTO @ 1967 Rpm

? 540E PTO @1560 Rpm

? 1”3/8 -6 Spline PTO Shaft

WHEEL EQUIPMENT & MISCELLANEOUS

? Adjustable Radial Wheel Equipment

? 320/70R24 Front 420/85R30 Rear

? Front Weight Frame

? Rear Weight Ballast 180 kg

? Front Dynamic Fenders

OPERATOR ENVIRONMENT

? 2 Post ROPS Frame

? FOPS Falling Object Protection

? Flat Floor ISO Mounted Platform

? Rubber Floor Mat

? Ergonomic Controls

? Telescopic and Tilting Steering Wheel

? Digital Dash

? Deluxe PVC Mechanical Seat

? Sun Canopy

? Telescopic Mirrors

? 2 Rear Work lights

? 2 Bonnet Work lights

? Rotating Beacon

HYD/LINKAGE/DRAWBAR

? Open Centre Hydraulic System

? 56 I/min Hyd Pump

? Separate 20 L/min Steering Pump

? 3 Sets of Remotes

? Kickout/Detent/Float

? Mechanical Three Point Linkage

? Position & Draft Control Settings

? Cat 2 Ball ends

? 3500kg lift capacity

? Swinging Drawbar – CAT A

WEIGHTS & DIMENSIONS

Wheelbase: 2106mm

Length: 3860mm

Total Height: 2498mm

Total Weight: 3250kg
